Product Details:
|
| Synonym: | Aerospace Aluminum Alloy Plate | Alloy: | 7075 |
|---|---|---|---|
| Temper: | O/T4/T6 | Application: | Aircraft/Aerospace |
| Certificate: | Aviation/NADCAP Certified | Thickness: | 0.2-3.5mm |
| Width: | 1200-2650mm | Length: | 2000-12000mm |
| Property: | Low Density, Moderate Strength, Easy Processing And Forming | ||
| Highlight: | T6 Temper Aluminum Alloy Plate,T4 Temper Aluminum Alloy Plate,O Temper 7075 Aluminum Plate |
||
7xxx High Anti-Corrosion Aerospace Aluminum Alloy Plate
We are supplying the 7xxx series aluminum alloy plate,including 7020/7N01/7075/7050,which are widely used for aero& aviation,railway transportation, automotive ,marine and offshore engineering,energy sources,tool and mould etc.
The 7xxx series aluminum alloy has many good advantages,for example:low density, moderate strength, easy processing and forming, strong corrosion resistance, abundant resources and strong recyclability, the development of aviation industry has formed an inexplicable relationship with the application of aluminum alloy materials.
Specification of 7xxx aluminum alloy plate:
Alloy: 7020/7N01/7075/7050
Temper: O/T4/T6
Thickness: 0.20-3.5mm or as per customers' requirement
Width: 1200-2650mm or as per customers' requirement
Length: 2000-12000mm or as per customers' requirement
We are supplying the extra thick,extra wide and extra long aluminum alloy plate.
Other sizes is available according to customer's request.Besides aluminum alloy plate,we are also supplying the aluminum coil as per customers' requirement.
Application:
| 7xxx | 7050 | Radar structural parts ,manufacturing structure of aircraft, other high stress structural elements which demand high strength and strong corrosion resistance etc. |
| 7075 | Aviation, aerospace, moulding, mechnical equipment, tooling and fixture etc. | |
| 7N01 | Bed plate of high speed train and coal transportation vehicle etc. | |
| 7021 | Unit load device of aviation,components for aerospace and aviation |
Typical Chemical composition:
| ALLOY NO. | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 7075 | 0.4 | 0.5 | 1.0-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | Rem |
| 7050 | 0.12 | 0.15 | 2.0-2.6 | 0.1 | 1.9-2.6 | 0.04 | 5.7-6.7 | 0.06 | Rem |
Terms and conditions:
Trade term:CIF / CFR / FOB
Payment term:30% before production+70% before shipment;or 100% Irrevocable L/C at sight;Or we can further cummunicate with each other about this part.
Shipment:Normally it is about 30-35days
MOQ:5 metric tons for each thickness. (Normally it is formed according to the concrete specifications.)
Quantity tolerance:+/-10% of total quantity as confirmed PI.
