Product Details:
|
| Alloy: | 4343 / 3003+0.5%Cu | Clad Layer: | 4343 |
|---|---|---|---|
| Type: | Brazing | Application: | Intercooler |
| Size: | 1.5 - 3.0 Mm | Temper: | HO |
| Cladding Ratio: | 4 - 8% For Each Side | ||
| Highlight: | polished aluminium sheet,aluminium sheet metal |
||
Alloy 4343 / 3003+0.5% Cu Aluminium Heat Exchanger With High Strength Side Plate For Intercooler
Core Material
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | － | 0.1 | 0.05 | 0.03 | 1 |
Cladding Material
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
| 4343 | 6.8 - 8.2 | 0.8 | 0.25 | 0.1 | - | 0.20 | － | 0.05 | 1 |
Produce capability
| Width(mm) | Thickness(mm) | Length(mm) | Inside Diameters(mm) | |
| Sheet | 500-1070 | 0.5-5.0 | 500-2500 | As customer request |
| Pre-Braze Strenght ( Mpa) | Post - Braze Strength ( Mpa ) |
|
Alloy
|
Temper | Yield Strength | Tensile Strength | Temsile Strength | Yield Strength |
|
4343/3003+0.5%Cu
|
HO | > / = 45 | 120 -150 | 140 | 45 |
Our advantage
1 . Manufacturer and Distributer, we can supply different brand and series plate and gasket,
2 . As manufacturer, we can supply the best quality replace parts for above brands to help you save cost.
3 . Over 10 years experience on the energy field, we also can provided technical service such as technical consultation, equipment update, capacity expansion scheme, maintenance and cleaning of the equipment.
4 . ISO9001:2008 international quality standard certification.
